Perkins 45KVA Diesel Silent Generator Heavy Duty 3phase

Generator Set Specifications
Minimum Rating
45 kVA / 36 kW
Maximum Rating
50 kVA / 40 kW
Emissions/Fuel Strategy
Fuel Optimised
50 Hz Prime
45 kVA / 36 kW
50 Hz Standby
50 kVA / 40 kW
60 Hz Prime
– / –
Frequency
50 Hz
Speed
1500 RPM
Voltage
220-415 Volts
50 Hz Prime Rating
These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power. There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hour in 12 hours.
60 Hz Prime Rating
These ratings are applicable for supplying continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted on these ratings. The alternator on this model is peak continuous rated (as defined in ISO 8528-3).
50 Hz Standby Rating
Standard reference conditions 25�C (77�F) Air Inlet Temp, 100m (328 ft) A.S.L. 30% relative humidity. Fuel consumption data at full load with diesel fuel with specific gravity of 0.85 and conforming to BS2869: 1998, Class A2.
Engine Specifications
Engine Model
Perkins® 1103C-33TG2/3
Bore
105 mm (4.1 in)
Stroke
127 mm (5 in)
Governor Type
Mechanical
Displacement
3.3l (201.4 cu. in)
Compression Ratio
18.23:1
